為延長噴碼機使用壽命，提高設備使用率和完好率，減少故障率。現將我公司噴碼機日常維護及保養知識與大家分享。
In order to prolong the service life of the jet printer, improve the utilization rate and intact rate of the equipment, and reduce the failure rate. Now we share our daily maintenance and maintenance knowledge with you.
一、噴碼機日常使用注意事項：
1. Notices for the daily use of jet printers:
1、因噴碼機使用的油墨和稀釋劑非常容易燃燒，所以須在良好通風處安放噴碼機，遠離火源、火焰和靜電。
1. Because the ink and diluent used in the jet printer are very easy to burn, it is necessary to place the jet printer in a well-ventilated place, away from fire, flame and static electricity.
2、不要遺留油墨、清洗劑浸泡過的碎布和碎紙片在噴碼機旁。
2. Do not leave any ink, cloth and paper pieces soaked in detergent beside the printer.
3、 嚴禁在噴碼機附近吸煙，應懸掛“禁止煙火”和“易燃油墨”標志在噴碼機附近。
3. Smoking is strictly prohibited near the printer. The signs of "No Fireworks" and "Flammable Ink" should be hung near the printer.
4、在噴碼機附近放置二氧化碳滅火器（比較遠距離10米）。
4. Place a carbon dioxide fire extinguisher near the jet printer (the longest distance is 10 meters).
二、噴碼機電氣連接注意事項
II. Notices for Electrical Connection of Jet Coder
1、 接到220V單項電源（含地線），必須使用原廠電源線，連接到固定的、安裝有地線的電源插座上。
1. When connected to 220V single power supply (including ground wire), the original power supply cable must be used and connected to a fixed power socket with ground wire.
2、 地線的連接必須遵守有關規定。如果地線接觸不良，有可能造成噴碼機主板的損壞或引起其它潛在危險。
2. The connection of ground wires must comply with the relevant regulations of the state. If the ground wire contact is not good, it may cause damage to the printer motherboard or other potential hazards.
三、日常維護保養注意事項
3. Daily maintenance matters needing attention
1. 使用噴碼機油墨、稀釋劑時對禁止配戴隱形眼鏡。
1. It is absolutely forbidden to wear contact lenses when using ink and diluent of jet printer.
2. 當添加油墨或稀釋劑操作時，建議使用抗溶劑手套和防護鏡。
2. Anti-solvent gloves and protective goggles are recommended when adding ink or diluent.
3. 噴碼機日常保養過程如下：
3. The daily maintenance process of the jet printer is as follows:
?北京噴碼機維護保養主要是管路、噴頭保養：
Maintenance of Beijing Printer is mainly pipeline and nozzle maintenance.
a) 墨水更新：先將管路里的墨水全部抽空，稀釋劑注入墨水罐運行1h后全部 排出，再次加入稀釋劑運行0.5h后全部排出，加入原廠墨水。建議機器每使用一年進行一次墨水更新，保證設備運行更加穩定。（抽出的廢液不建議二次使用，以免造成管路堵塞） a) 噴頭清洗：對于不具備自動清洗功能的噴碼機，建議每天開關機時清洗，以 確保機獲得高品質的打印效果。在噴頭下方放置容器，用專用洗瓶裝入稀釋劑，對準噴嘴、充電極、檢測極、高壓偏轉板上的墨漬進行清洗，注意不要讓稀釋劑濺入口眼及皮膚，清洗干凈后，用紙巾將噴頭各部件的清洗劑擦干。
(a) Ink renewal: first, all the ink in the pipeline is exhausted, diluent is injected into the ink tank for 1 hour, then all the ink is discharged after adding diluent for 0.5 hours, and then the original ink is added. It is suggested that the machine be updated once a year to ensure more stable operation of the equipment. (Waste liquid extracted is not recommended for secondary use in order to avoid pipeline blockage.) a) Sprinkler cleaning: For the sprinkler without automatic cleaning function, it is recommended that the machine be cleaned when switched on and off every day to ensure high quality printing effect. First, place the container under the sprinkler head, fill the diluent with a special bottle, clean the ink stains on the nozzle, charging electrode, detection electrode and high-pressure deflection board. Take care not to let the diluent splash into the eyes and skin. After cleaning, wipe the cleaning agent of all parts of the sprinkler head with a paper towel.
b) 調整墨線：若發現墨線偏離回收器，進行噴嘴打通，用專用洗瓶加入少 許稀釋劑至噴嘴帽，反復打通3次左右，如墨線始終在同一位置則需進行人為調節噴腔。墨線標準：正對回收器觀察，墨線噴入回收器三分之一處且略左。（側看墨線在回收器正中間）
B) Adjust ink line: If the ink line deviates from the reclaimer, the nozzle should be opened first, a little diluent should be added to the nozzle cap with a special washing bottle, and the nozzle cap should be opened three times or so repeatedly. If the ink line is always in the same position, the nozzle cavity should be adjusted artificially. Ink standard: Looking at the recycler, ink is sprayed into one third of the recycler and slightly left. (Look sideways at the ink line in the middle of the receiver)
二）噴碼機長時間停機后的維護 任何一次停機，無論時間長短，只要該噴碼機在每周內開機運行2次，并打開墨線至少持續運行或油墨更新一個小時，這樣就可以用若干次短停機替代長時間的停機。
2) Maintenance of any downtime of the jet printer after a long downtime, regardless of the length of time, as long as the jet printer runs twice a week, and opens the ink line to run continuously or ink updates for at least one hour, it can replace the long downtime with several short downtime.
1）噴碼機停機時間為8-15天：對喉管和噴頭進行一次清洗，噴頭朝上放置，防止墨水回流。
1) Inkjet printer shutdown time is 8-15 days: the throat and nozzle are cleaned once, the nozzle is placed upward to prevent ink reflux.
2）噴碼機停機時間超過15天：此時必須將機器內的墨水排放后加入稀釋劑運行，完畢后把噴頭朝上放置，防止墨水回流。
2) The stop time of the printer is more than 15 days. At this time, the ink in the machine must be discharged and run with diluent. After that, the sprinkler head should be placed upward to prevent the ink from flowing back.
3）長時間停機后啟動噴碼機注意事項 停機8-30天后噴碼機的啟動，如有必要，檢驗一下墨線穩定性。進行一次5分鐘的噴嘴打通。
3) Start the printer after a long downtime. Notes: Start the printer 8-30 days after the downtime. If necessary, check the stability of the ink line. Make a 5-minute nozzle pass.
4)停機時間超過30天
4) Over 30 days of downtime
將管路中的油墨排空。加入稀釋劑運行一小時，疏通因長時間停機而堵塞的管路。稀釋劑運行時可進行一次5分鐘的噴嘴打通。稀釋劑運行完畢后排空管路，加入新油墨，再打通噴嘴3分鐘使墨線位置更加穩定。
Empty the ink in the pipeline. Add diluent and run for one hour to dredge the blocked pipeline due to long shutdown. When the diluent is running, the nozzle can be opened for 5 minutes at a time. After the diluent is running, the drainage pipe is emptied, new ink is added, and the nozzle is opened for 3 minutes to make the ink line position more stable.
5) 噴碼機維護保養周期。 每15天對噴碼機管路進行一次檢查，是否老化、接頭是否松動 更換過濾器。該操作視環境而定，如粉塵較大至少每隔4個月更換一次，正常情況下應該每隔12個月進行一次。機器內部除塵。該操作至少應該每隔1個月進行一次。
5) Maintenance cycle of jet printer. Every 15 days, check the pipeline of the jet printer, whether it is ageing, whether the joints are loosened and the filters are replaced. The operation depends on the environment. If the dust is large, it should be replaced at least every four months. Normally, it should be done every 12 months. Dust removal inside the machine. The operation should be performed at least once every 1 month.
四、噴碼機耗材的使用和保管注意事項
IV. Notices for Use and Maintenance of Consumables for Printers
1、噴碼機使用的消耗品揮發性強，保管時，應低于35度，避免高溫，遠離火源、熱源，必須密封良好并貯藏在蔭涼通風處（封閉性好的厚壁鐵柜內貯存）。
1. The consumables used in the jet printer are highly volatile. They should be kept below 35 degrees, avoid high temperature and keep away from fire and heat sources. They must be well sealed and stored in a shady and ventilated place (in a thick-walled iron cabinet with good sealing).
2、噴碼機的消耗品的保質期是一年。
2. The shelf life of consumables of jet printer is one year.
3、噴碼機的消耗品嚴格對應品牌使用，不得使用替代品，否則會給設備造成嚴重傷害。
3. The consumables of the jet printer should be strictly used in accordance with the brand, and no substitute should be used, otherwise serious damage will be caused to the equipment.
